The ASUS TUF Gaming B760M-BTF WIFI is part of ASUS's innovative BTF ("Back To Future") lineup, relocating all major connectors — power, SATA, fan — to the underside of the board. The result is a completely unobstructed top view of the PCB, ideal for builds that use glass-front cases or reverse-connector motherboard pairings. Intel Wi-Fi 6 and 2.5Gb LAN ensure fast and stable connectivity out of the box.
Socket / Chipset: Intel LGA1700 / B760, compatible with 12th and 13th Gen Intel Core processors
Hidden connector design: All 24-pin ATX, SATA, fan, and front-panel headers routed to the board's underside
Memory: 4× DDR5 DIMM slots, up to 192GB; supports ASUS EXPO overclocking profiles
Storage: 3× PCIe 4.0 M.2 slots with M.2 heatsinks, plus SATA 6Gb/s ports
Networking: Intel Wi-Fi 6 (802.11ax, up to 2.4 Gbps), Realtek 2.5Gb LAN with TUF LANGuard
Power delivery: 12+1 DrMOS power stages rated at 50A each; enlarged VRM heatsinks
